stainless steel Solar Hot Water/ Solar Water Heater/tube collector

FOB Reference Price:Get Latest Price
US $110-380 / Set | 3 Set/Sets (Min. Order)
Supply Ability:
3000 Set/Sets per Month
Port:
Shanghai port
Report Suspicious Activity
Overview
Quick Details
Type:
Evacuated Tube
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Heating System:
Thermosyphon (Passive)
Connection Type:
Direct-Plug
Installation:
Freestanding
Housing Material:
Stainless Steel
Certification:
CE, SRCC, Solar Keymark,ISO
Capacity:
200
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
AUDARY or OEM
Model Number:
ADL-6038
name:
solar heater
material:
stainless steel
vacuum tube size:
47x1700mm or 58x1800mm
tank capacity:
100L, 150L, 200L etc
Packaging & Delivery
Packaging Details
full container load: Carton
less container load:wooden box
Delivery Time
10 days after down payment

 Solar Hot Water/ Solar Water Heater:

  1. The material of the outer tank is stainless steel. The material of inner tank is SUS304 2B.
  2. The life of the vacuum tubes is 15 years.
  3. Stable and reliable performance, well resistance.
  4. Temperature when exposed to sun without water: 250°C, 2.5 hours to boiling point if using single tube.
  5. It resists 25mm hail.
  6. Heat preservation: 72 hours.
  7. Optional accessories: assistant tank, electrical heater.
  8. 5 years warranty.



MaterialEvacuated tubeHigh borosilicate glass, with aluminum absorption layer of magnetron sputtering
Inner tankSUS 304-2B food-grade stainless steel,Φ360mm
Outer tankColor coated galvanized steel,Φ470mm
BracketGalvanized steel with electrostatic plastic-sprayed
ThicknessInsulation layer55mm
Inner tank1.2mm
Outer tank0.4mm
Bracket1.5mm
AccessoriesFastenersStainless steel screws.
Sealing ringMacromolecule silicone rubber.
othersP/T valve, electrical heater,magnesium rods, relief valve
SpecificationHeat preservation 72 hours
Hail resistance 20-30mm
Max Water Temperature Can reach at least 95 degree
Circulation  Indirect /Closed loop (Active)
Heating System  Thermosyphon (Passive)
Connection Type  Direct-plug
Absorption Rate ≥0.95±0.02
Emission Rate ≤0.20±0.02
Vacuum Tightness P≤5.0*0.0001Pa
Idle sunny property parameres Y=220-260./KW
Total Weight 110KGS
Certifications Solar Keymark, SRCC, SGS, CE, ISO9001
Warranty 5 years







.
